JCB 525-60 Telehandler

Engine

Model - JCB Diesel by Kohler
Power - 55kW
Torque - 300Nm @ 1500rpm
Displacement - 2.5 litres
Number of cylinders - 4

Transmission

Type - Hydrostatic
Modes - 2 Speed
Drive - Permanent 4 Wheel Drive
Maximum speed - 25kph

Electrical System

System voltage - 12 volt
Alternator output - 100 Amp hour
Battery capacity - 120 Amp hour

Hydraulics

Maximum system pressure - 260 bar
Flow rate - 80 ltr/min
Joystick control - Single lever Servo
Steer modes - 3 modes
Cycle times
Boom Raise - 7.6s
Boom Lower - 5.3s
Extend - 7.5s
Retract - 3.7s
Bucket Dump - 1.9s
Bucket Crowd - 2.9s

Service Capacities

Fuel tank - 65 litres
Hydraulic tank - 75 litres

Brakes

Service brakes - Hydraulically operated self adjusting
Parking brake - SAHR Handbrake self adjusting

Options

Cab
ROPS ISO3471 - Standard
FOPS ISO 3449 - Standard
Hourmeter - Standard
Adjustable fabric seat - Standard
Digital dash display - Standard
LiveLink telemetrics - Standard
Load control system (LMI) - Standard

Accessories
Reversing alarm - Standard
Halogen work lights - Optional
LED work lights - Optional
Amber beacon - Optional
Green beacon with orange seat belt - Optional
Competitor carriages - Optional
Window guards - Optional
Sun blind - Optional
Immobiliser - Optional
Air conditioning - Optional
FM radio kit - Optional
